R410A 60Hz EER 2.36 Series Service Manual
Part Name Quantity No. Part Name Quantity
1 Right mounting plate of evaporator 1 15.7 Evaporator left lower mounting plate 1
2 Horizontal step motor 1 16 Water tray assy 1
3 Wind guide assembly 1 16.1 Water tray foam assembly 1
4 Rear cover with cotton 1 16.2 Horizontal swing leaf mount 1 1
5
Right side board assembly
1 16.3 Horizontal swing leaf mount 2 1
6 Horizontal step motor 1 16.4 Horizontal swing leaf active rod 1
7
1 16.5 Horizontal swing leaf connecting rod 1 1
8 Indoor PCB assembly 1 16.6 Horizontal swing leaf connecting rod 2 1
8.1 E-part box 1 16.7 Wind guide blade 1
8.2 Indoor PCB 1 16.8 Vertical stepper motor 1
8.3 Terminal 1 17 Display panel assembly 1
8.4 Transformer 1 17.2 Show mask 1
8.5 Blade fan capacitor 2 17.3 Display board mounting box 1
9 Electric box cover 1 18 Back style assembly 2
10 Chassis assembly 1 18.1 Back style 2
11 Support bar 1 18.2 Filter 2
12 Pipe plate 1 18.3 Grille buckle 6
13 Indoor fan motor 2 18.4 Grille screw cover 6
14 Upper volute 4 19 Top cover assy 1
15
1 20 Wind guide bracket 2
15.1 Evaporator assembly 1 21 Centrifugal fan blade 4
15.2 Evaporator return header assembly 1 22 Lower volute 4
15.3 Evaporator splitter capillary assembly 1 23 Motor bracket 2
15.4 Evaporator right mounting plate 1 24 Middle beam welding assembly 1
15.5 Evaporator left mounting plate 1 25
Left side board aessembly
1
15.6 Evaporator right lower mounting plate 1 26
