PC Health Status Menu
Select PC Health Status from the CMOS Setup Utility menu and press Enter
to display the PC Health Status menu.
Figure 9. PC Health Status Menu
All of the values shown in Blue are dynamic and change as the speed and
voltages of the various components change with system usage.
 :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F7:Defaults
 SmartFan Function [Press Enter]
VCC 3.3V 3.28V
CPU Vcore 1.19V
DIMM Voltage 1.48V
CPU VTT Voltage 1.23V
IOH Vcore 1.08V
VCC 4.96V
+12V 12.10V
3VSB 3.23V
VBT 3.15V
CPU Temperature 31
o
C
NB Temperature 55
o
C
VREG Temperature 50
o
C
System Temperature 33
o
C
CPU Fan Speed 3054 RPM
Power Fan Speed 0 RPM
Chassis Fan Speed 0 RPM
Item Help
Main Level 
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
