- 12 -
Align the notches on the CPU to the notches in
the socket.
Lower the processor straight down into the
socket.
Note: Make sure the CPU is fully seated and level
in the socket.
Lower the load plate so it is resting on the CPU.
Press the right socket lever down to lock into
place.
Carefully lock the left lever back into place.
Installing the CPU Cooling Device
There are many different cooling devices that can be used with this
motherboard. Follow the instructions that come with your cooling assembly.
