2.4 Technical features
Electrical
MTP 40-10 & 50-10 MTP 60-10
Electric supply
220 / 240 Volt (AC)
Frequency
50 Hz
Current absorption
0,6 Amps
Hydraulic connections
Primary circuit supply
¾” ext. thread 1” ext. thread
Primary circuit return
¾” ext. thread 1” ext. thread
Apartment circuit supply
¾” ext. thread ¾” ext. thread
Apartment circuit return
¾” ext. thread ¾” ext. thread
DHW supply
¾” ext. thread 1” ext. thread
DCW inlet
¾” ext. thread 1” ext. thread
Drain
¾” ext. thread ¾” ext. thread
Hydraulic characteristics
Primary circuit max pressure
10 bar Standard / 16 Bar Optional
Apartment heating circuit
recommended cold fill pressure
1.5 bar
DHW max static pressure
4 bar
DCW min static pressure
0,5 bar
Max supply temperature (Primary)
90 °C
Min supply temperature (Primary)
70 °C
Recommended primary flow rate
800 l/h
Secondary heating circuit
expansion vessel size
8 litres
Weight
Dry Shipping
Weight 40-10
32 kg 33 kg
Weight 50-10
34 kg 35 kg
Weight 60-10
TBC TBC
Part number
The part number identifies the unit model and the components fitted on board, for instance
MTP40-10 means
 MTP: ModuSat Twin Plate
 40: number of DHW plates (and also nominal capacity) of plate heat exchanger
 10: number of Heating plates (and also nominal capacity) of plate heat exchanger
