Evinox ModuSat TP 40-10 - Wall Fixing

19
3.6 Wall fixing
The ModuSat TP is designed for wall mounting using brackets to be screwed to the wall as
shown below.
33,5 60 60 60 120 60
427
11 144,5 144,5
166
143
42,5
710
Please note – Weights of the units are shown in the technical table on page 14.
