Evinox ModuSat XR - Technical Parameters

8 2551868AB
Technical Parameters
Electrical
XR 30/55-/70…
XR-ECO 30/55-77…
XR 100-XX
Electric supply
220 / 240 Volt (AC)
Frequency
50 Hz
Current absorption
0,6 Amps
Hydraulic connections
XR 30/55-/70…
XR-ECO 30/55-77…
XR 100-XX
Primary circuit supply
A
3/4 ” BSP
1 ” BSP
Primary circuit return
B
3/4 ” BSP
1 ” BSP
DCW inlet
C
3/4 ” BSP
1 ” BSP
DHW supply
D
3/4 ” BSP
1 ” BSP
Apartment circuit supply
E
3/4 ” BSP
3/4 ” BSP
Apartment circuit return
F
3/4 ” BSP
3/4 ” BSP
Drain
G
1/2 ” Compression
1/2 ” Compression
Hydraulic characteristics
XR 30/55-/70…
XR-ECO 30/55-77…
XR 100-XX
Pipework material
Copper
Plate heat exchanger material
Stainless steel 316L
Operating medium
Water
Primary circuit max pressure
16 bar
Primary minimum differential
pressure
50 kPa* (0.5 bar)
*may vary depending on the required output
Primary maximum differential
pressure
400 kPa (4 bar)
Apartment heating circuit
recommended cold fill pressure
1.0 bar
Apartment heating maximum pressure
3 bar
Apartment heating expansion vessel
8 L
DHW max pressure
10 bar
DCW min pressure
1 bar
Max supply temperature (Primary)
85°C
Mass
Dry
Wet
XR ECO TP-30-10R
34.5 kg
36.5 kg
XR ECO TP-55-10R
35 kg
37.5 kg
XR ECO TP-70-10A
37 kg
39.5 kg
XR TP-100-10A
43 kg
47.5 kg
For other models please contact Evinox.
