Evinrude E10EL4 User Manual

11
2
NAMES OF PARTS
MODEL
Item
TP P
Overall Length mm (in)
975 (38.4) 590 (23.2)
Overall Width mm (in)
354 (13.9) 320 (12.6)
Overall Height S·L·XL mm (in)
1,035 (40.7) · 1,162 (45.7) · 1,289 (50.7)
Transom Height S·L·XL mm (in)
435 (17.1) · 562 (22.1) · 689 (27.1)
Weight
S Kg (lb)
46.5 (102.5) 46.0 (101.4)
L Kg (lb)
47.5 (104.7) 47.0 (103.6)
XL Kg (lb)
49.0 (108) 48.5 (106.9)
Output kW (Hp)
5.9 (8) 7.2 (9.8)
Max. Operating Range rpm
5,000-6,000
Idle Speed in Forward Gear rpm
900
Idle Speed in Neutral Gear rpm
950
Engine Type
4-Stroke
Number of Cylinder
2
Bore
×
Stroke mm (in)
55
×
44 (2.17
×
1.73)
Piston Displacement mL (Cu in)
209 (12.8)
Exhaust System
Through hub exhaust
Cooling System
Water cooling
Engine Lubrication
Trochoid pump
Startring System
Electric starter motor
＊
Ignition System
Flywheel Magneto C.D. ignition
Spark Plug
NGK DCPR6E
Trim Position
6 3
Engine Oil
NMMA FC-W certified 10W-30 or
API SF, SG, SH, SJ, SL or SM, 10W-30/40, Approx. 800mL
Gear Oil
Genuine Gear Oil or API GL5,
SAE #80-90, Approx. 320mL
Fuel
Unleaded regular gasoline : Pump posted 87 Octane
(research octane rating of 91)
Fuel Tank Capacity L (US gal)
12 (3.17)
Gear Reduction Ratio
2.08 (13 : 27)
Emission Control System
Engine modification (EM)
Operator Sound Pressure
(ICOMIA 39/94) dB(A)
7.7
Hand Vibration Level
(ICOMIA 38/94) m/sec2
2.2 —
＊
: with manual
※
Specifications subject to change without notice.
10
OM_E_10HP_body_111213.indd 11 11/12/13 13:23

Evinrude E10EL4 Specifications

General

Brand	Evinrude
Model	E10EL4
Category	Outboard Motor
Language	English
