30
ENGINE OPERATION
6
2. Feeding the fuel
Except for USA and Canada model
①
Full open the air vent screw on the
tank cap.
②
Open the fuel tank cap slowly and
release internal pressure com-
pletely. After that, close the fuel
tank cap.
③
Connect the fuel connector to the
engine and squeeze primer bulb
until it becomes stiff to feed fuel to
carburetor. Direct arrow mark up-
ward when priming.
Engine side
Fuel tank side
For USA and Canada model
①
Full open the air vent screw on the
tank cap.
②
Loosen the tank cap until contacts
the tab lock and release internal
pressure completely. After that,
close the tank cap. until two click
sound is heaed.
③
Connect the fuel connector to the
engine and squeeze primer bulb
until it becomes stiff to feed fuel to
carburetor. Direct arrow mark up-
ward when priming.
Engine side
Fuel tank side
