TOOL KIT AND SPARE PARTS
12
The following a list of the tools and spare parts provided with the motor.
Items Quantity Remark
Service tools
Tool bag
Pliers
Socket wrench
Socket wrench
Socket wrench handle
Screwdrivers
Screwdriver handle
1
1
1
1
1
1
1
10
×
13 mm
16 mm (spark plug)
Cross-and straight-point
Spare parts
Starter rope
Spark plug
Split pin
1
1
1
1,600 mm
NGK DCPR6E
Parts Packaged
with Engine
Fuel tank
Primer bulb
1
1 set
12L
Remote control box
Harness sleeve
Bracket bolts, nuts and
washers
1 set
1
1 set
E/TP only
E only 12-90mm (Tool bag)
E only
Bracket fixing
Bolt
Nut
Washer
4
4
4 (big)
4 (small)
8 mm P/TP only
8 mm
 〃
8 mm
〃
8 mm
〃
