COMPONENT IDENTIFICATION – MANUAL TILT MODELS
Item Description Item Description
8 Oil Tank 13 Battery Cable
(electric start models only)
9 Oil Fill Cap 14 Fuel Connector
10 Fuse 15 Spark Plugs
11 Spare Fuse 16 EMM (Engine Management Module)
12 Air Silencer 17 Rewind Starter / Flywheel Guard
Starboard
17
16
15
008495
14
12
11
9
8
13
008494
Port
10
