23
ENGINE OPERATION
6
For USA and Canada model
①
Full open the air vent screw on
the tank cap and release internal
pressure.
Full open
Air vent screw
Full open
Air vent screw
Tab lock
②
When using integral tank
Open the fuel tank cap slowly.
When using separate tank
Lo os e n th e ta n k ca p un t il i t
contacts the tab lock and release
internal pressure completely. After
that, press down the tab lock and
open the tank cap.
③
When using integral tank
Remove top cowl and fill the fuel
not to over the full mark.
When using separate tank
Fill the fuel carefully not to over
flow.
Full mark
④
After filling the tank, close the tank
cap until two clicks sound is heard.
