Evinrude E4RL4 - Periodic Inspection

44
INSPECTION AND MAINTENANCE
10
It is important to inspect and maintain your outboard motor regularly. At each
interval on the chart below, be sure to perform the indicated servicing. Maintenance
intervals should be determined according to the number of hours or number of
months, whichever comes first.
2. Periodic inspection
Description
Inspection intervals
Inspection procedure Remarks
First 20
hours or 1
month
Every 50
hours or 3
months
Every 100
hours or 6
months
Every 200
hours or
1 year
Fuel
System
Carburetor *1
○ ○
Strip, Clean, and adjust.
Fuel Filter
○ ○ ○ ○
Check and clean or Replace if
necessary.
Entire cartridge
Piping/Hoses *2
○ ○ ○ ○
Check and clean or Replace if
necessary.
Fuel Tank *2
○ ○ ○
Clean
Fuel Tank Cap *2
○ ○ ○ ○
Check and clean or Replace if
necessary.
Fuel Pump *1
○ ○ ○ ○
Check and clean or Replace if
necessary.
Disassemble and
check each 300
hours.
Ignition
Spark Plug
○ ○ ○
Check gaps.
Remove carbon deposits or
Replace if necessary.
0.8-0.9mm
(0.031-0.035in)
Ignition Timing *1
○ ○ ○
Check timing.
Starting
System
Starter Rope
○ ○ ○ ○
Check for wear or chafing.
Engine
Engine Oil
Replace
○
Replace
○
Replace
○
Replace if necessary.
Valve Clearance *1
○ ○ ○
Check & adjust.
Thermostat *1
○ ○
Check and Replace if necessary.
Lower
Unit
Propeller
○ ○ ○ ○
Check for bent blades, damage,
wear.
Gear Oil
Replace
○
○
Replace
○
Replace
○
Change or replenish-oil and
check for water leaks.
195mL (6.6 fl.oz)
Water Pump *1
○ ○ ○
Check for wear or damage.
Replace impeller
every 12 months.
Warning System *1
○ ○ ○
Check function.
Bolts and Nuts
○ ○ ○ ○
Retighten
Sliding and Rotating Parts.
Grease Nipples
○ ○ ○ ○
Apply and pump in grease.
Outer Equipment
○ ○ ○ ○
Check for corrosion.
Anode
○ ○ ○
Check for corrosion and
defomation.
Replace if
necessary.
*1 Have this handled by your dealer.
*2 I n USA, you have to use EPA approved part. (See P16 - P17).
