Fuel and Oil - 23
Installing the Oil Return Hose
Connect the oil return hose to the oil return hose fit-
ting on the motor. Secure with the clamp (15.7 mm)
from the owner’s kit.
1. Oil return hose - 5/16 in. (8 mm) - Blue stripe
2. Oil return hose fitting - 5/16 in. (8 mm) - Blue
stripe
3. Clamp (15.7 mm) from owner’s kit
Start the engine and run at idle only. Restrict the oil
return hose for about 15 - 20 seconds. Shut off the
engine.
1. Restrict Oil return hose - 5/16 in. (8 mm) - Blue
stripe
WARNING
Prevent injury from moving engine compo-
nents. Before starting the engine...
Shift it to NEUTRAL
Keep hands, clothes, hair clear of power-
head
Remove the propeller if you use a flushing
device
Read Engine Starting, ENGINE STOPPING
