5. Plan the Installation Type Based on Your Version
There are 2 versions of EVIQO Smart EV Chargers:
1) plug-in version which comes with the input cable with NEMA 14-50 plug
and
2) hardwire version which comes with the 3-wire whip, liquid tight fitting and a conduit for
hardwiring.
Choose the desired charging amperage first. EVIQO Smart EV Charger provides a
maximum of 48A and offers installation options for various amperages. Consider factors
such as available space or electrical capacity in the panel, desired charging speed, proper
outlet availability and the homeowner's preference for hardwired or plug-in installation.
ATTENTION: EVIQO Smart EV Charger plug-in version with
NEMA 14-50 plug is pre-set for the default 40 Amps out of the
box which is the maximum amperage allowed by the
regulations for NEMA 14-50 outlet. To get the maximum of 48
Amps, hardwire installation is required.
EVIQO Smart EV Charger hardwire version with 3-wire whip
and nonmetallic liquid tight flexible electrical conduit is set
for the default 48 Amps out of the box and requires a 60 Amps
dedicated circuit.
EVIQO Smart EV Charger plug-in version is equipped with NEMA 14-50 input power plug
and is pre-set for 40 Amps of Max Output Load (Number 2 on the Amperage Dip Switch
located inside the device) by default. Depending on the preferences, the device can be
plugged-in or hardwired too (hardwire custom whip is required). If hardwired installation is
chosen and the user wishes to increase the Max Output Load to 48 Amps (which requires
60 Amps Dedicated Circuit) - please switch to “3” on the Amperage Dip Switch.
EVIQO Smart EV Charger hardwire version is equipped with 3-wire whip of 3.2ft with
nonmetallic liquid tight flexible electrical conduit of 3,2ft for hardwiring. The Dip Switch is
pre-set for 48 Amps of Max Output (Number 3 on the Amperage Dip Switch located inside
the device) by default.
Amperage Dip Switch
