loading machine usage.
c) Consult a professional to
check for electrical short-circuits
and ensure dry J1772 connector.
d) Test the relay module with a
multimeter while the EV charger
is on. Use the AC voltage gear to
measure L1_IN and L1_OUT or
L2_IN and L2_OUT. If the voltage
is between 208V~240V, the relay
is disconnected; if the measured
value is 0V, the relay is closed.
Contact technical support if there
are any inconsistencies.
Leakage Protection
Activated
Flashing red 9
times
3 seconds interval
RCD (Residual Current
Device) Abnormal Fault.
RCD Fault is triggered
when current leaks at a
range of 15-20mA.
a) Unplug the J1772 connector
and reboot the charger.
b) If the fault persists, contact a
licensed electrician.
RCD Self-Test Fault
Flashing red 10
times
3 seconds interval
When the EV Charger is
powered on, it will
self-detect whether the
leakage detection
mechanism is effective.
a) Reboot the charger.
b) Please contact a licensed
electrician to fix the hardware
issue.
