INSTALLATION INSTRUCTIONS
Affinity 30G
Evo, Inc. | 8140 SW Nimbus Ave., Bldg 5 | Beaverton, Oregon 97008 USA
Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com
15
STEP 4: Slide the Affi nity 30G chassis into the countertop so it rests on top of the installed
brackets. Bolt unit to angle brackets using supplied 1/4” x 20 fasteners from underside.
INSERT CHASSIS IN COUNTERTOP
Use supplied 1/4” fasteners to bolt
chassis to angle brackets.
Gas Installation must be done by a licensed professional in accordance with
local guidelines once unit has been completely installed. Refer to pages 21-
24 for further instructions.
