2. Specifications
5
2.4 dimensions
unit-mm
MODEL: EVOHEAT 270
2. Specifications
2.5 performance parameters
6
Working Temp Range
(1).Ambient temperature is -7deg to 43deg(Heat Pump)
(2).The max temperature of water tank is 70
Measurement conditions:
Instant heating: Ambient temperature15DB/13WB,Water inlet 15 Water outlet 45
Operating parameters
The range of the operating water pressures: 0.15~0.7MPa
Model
Heating capacity
Water tank capacity
Power input
Running current
Power supply
Compressor Number
Compressor
Rated outlet water Temp.
Air volume
Nosie
Water inlet/outlet size
*Hydroboost Power heat
Net dimensions
Shipping dimensions
Net weight
Shipping weight
kW
kW
A
Deg C
3
m /h
dB(A)
inch
kW
mm
mm
kg
kg
EVOHEAT270 (PASHW015-270LD)
3.4
270
0.94
3.92
240V~/50Hz
1
rotary
55
450
49
3/4
1.5
See the drawing
135
175
720x760x2040
Picture 3
¦640
16
99
1435
1955
1194
1094
