EVOLT EV360 User Manual

Model
EV360
Measuring method
Tetra
-polar electrode method using 8 touch electrodes.
Frequency Range
5, 50, 250 kHz
Measuring site
Whole body and Segmental measurement (arms, legs, and trunk)
Main items
[Result for Body Composition Analysis]
Body Composition Analysis (Weight, LBM, Body fat, SLM, Protein, Mineral, TBW), Muscle/Fat analysis (Weight, SMM, Fat mass), O
besity analysis (BM, PBF, Obesity degree, AC),
Abdominal analysis (WHR, VFL, VFA), Control guide (Weight and control, Muscle mass and control, Fat mass and control, Target
to control, control to week, Duration to control),
ECW, Body composition change (Weight, SMM, Fat mass), Comprehensive evaluation (Body type, Biological age, BMR, TEE, BCM), Ba
lance assessment (Upper body L/R, Lower
body L/R), Segmental(Left arm, Right arm, Left leg, Right leg, Trunk) Fat mass/Lean mass, Impedance (Segmental & Frequency),
Blood pressure (when connected with blood
pressure monitor of our company), QR code
[Body Composition Analysis (Weight, LBM, Body fat, SLM, Protein, Mineral, TBW), Muscle/Fat analysis (Weight, SMM, Fat mass),
Obe
sity analysis (BMI, PBF, WHR), Child growth
curve (height, weight), Comprehensive evaluation (Body type, BMR, TEE, BCM, Obesity
degree), Balance assessment (Upper body L/R, Lower body L/R), Control guide (Target weight, Weight control, Muscle control, F
at control),
Segmental(Left arm, Right arm, Left leg, Right leg, Trunk) Fat mass/Lean
mass, Impedance (Segmental & Frequency), QR code
Current
Within 180μA
± 15
Power supply
Input: 100
-240VAC, 50/60Hz, 1.5 A Output: +12V, 5.0A
Display
12.5 Inch Wide Color LCD
Input device
Touch pad, PC remote control
Transmitting device
USB port , RS
-232C port
Printing device
USB port (the printer assigned by our company), Thermal print (option)
Dimension
641
× 436× 1029mm(W× D× H)
Weight
About 18kg (main unit)
Measuring range
100 ~ 950 Ω
Measuring time
Approx. 30 seconds
Input height
50 ~ 220 cm / 1ft 7.7in ~ 7ft 2.6in
Measuring weight
10 ~ 250 kg / 22lb ~ 551.1lbs
Applicable age
1 ~ 99 years old
Operation ambient
Ambient temperature range +5 to +40
°C. Relative humidity range 15 to 93 % (non condensing) Atmospheric pressure range 70 kPa (700 mbar) to 106 kPa (1060
mbar)
SPECIFICATION
Storage ambient
Ambient temperature range
-25 to +70 °C Relative humidity range lower than 93 % RH
Software name and
version
EV360 .AP.1.0.19 & BCA
-CE3F/V5.26.G & VNBCA-360/v0.19.2. NOTE. For purpose of improvement, specifications and design are subject to change without notice.
41
