CONTENTS
UV Diagram and components list PAGES 4 - 6
Flow Rates PAGE 7
Installing the quartz sleeve PAGE 8
Positioning and mounting the UV PAGE 9
Connection to your pipework PAGE 11
Water Testing PAGE 14
Connection to the Electricity Supply PAGE 15
Installing the UV bulb PAGE 16
UV Bulb Replacement PAGE 17
Replacing / Cleaning the Quartz Sleeve PAGE 18
Electrical box replacement PAGE 19
In Built Protection PAGE 19
Trouble Shooting PAGE 20
Frequently Asked Questions PAGE 21
Guarantee PAGE 22
UNBOXING THE UV
On unpacking, you will see that the UV bulb and quartz sleeve are packed separately for safe
transit. Please refer to pages 8 and 16 of this manual for instructions on how to install the bulb
and quartz sleeve. Quartz Sleeve O-Rings and End Cap Flat Washers are packed in separate
small bags inside the box.
Stainless steel mounting brackets and screws are also supplied in bags and need to be fitted.
On the 110 UV, the mounting brackets can be found in the cardboard end fitments.
Please take time to familiarise yourself with your UV and its components.
INTRODUCING THE EVOLUTION AQUA EVO UV
Congratulations on purchasing an Evolution Aqua evoUV. Our range of evoUV pond clarifiers
have been manufactured using the latest technology and design techniques. evoUVs have
been designed to clear green water which is caused by single celled green algae, and
prevent it from returning. evoUVs will work alongside many different filtration systems but
when used alongside Evolution Aqua’s pond filtration systems, the evoUV will deliver crystal
clear and healthy pond water.
Please read this instruction manual carefully from start to finish before attempting to install
your evoUV.
