Evolution Rage3 User Manual

20°
M- 43.22°
B- 14.00°
M- 34.32°
B- 11.60°
M- 28.48°
B- 9.85°
M- 24.35°
B- 8.53°
M- 21.27°
B- 7.52°
M- 18.88°
B- 6.72°
M- 16.98°
B- 6.07°
25°
M- 42.19°
B- 17.39°
M- 33.36°
B- 14.38°
M- 27.62°
B- 12.20°
M- 23.56°
B- 10.57°
M- 20.58°
B- 9.31°
M- 18.26°
B- 8.31°
M- 16.41°
B- 7.50°
30°
M- 40.89°
B- 20.70°
M- 32.18°
B- 17.09°
M- 26.57°
B- 14.48°
M- 22.64°
B- 12.53°
M- 19.73°
B- 11.03°
M- 17.50°
B- 9.85°
M- 15.72°
B- 8.89°
35°
M- 39.32°
B- 23.93°
M- 30.76°
B- 19.70°
M- 25.31°
B- 16.67°
M- 21.53°
B- 14.41°
M- 18.74°
B- 12.68°
M- 16.60°
B- 11.31°
M- 14.90°
B- 10.21°
40°
M- 37.45°
B- 27.03°
M- 29.10°
B- 22.20°
M- 23.86°
B- 18.75°
M- 20.25°
B- 16.19°
M- 17.60°
B- 14.24°
M- 15.58°
B- 12.70°
M- 13.98°
B- 11.46°
45°
M- 35.26°
B- 30.00°
M- 27.19°
B- 24.56°
M- 22.21°
B- 20.70°
M- 18.80°
B- 17.87°
M- 16.32°
B- 15.70°
M- 14.43°
B- 14.00°
M- 12.94°
B- 12.62°
50°
M- 32.73°
B- 32.80
M- 25.03°
B- 26.76°
M- 20.36°
B- 22.52°
M- 17.20°
B- 19.41°
M- 14.91°
B- 17.05°
M- 13.17°
B- 15.19°
M- 11.80°
B- 13.69°
55°
M- 29.84°
B- 35.40°
M- 22.62°
B- 28.78°
M- 18.32°
B- 24.18°
M- 15.44°
B- 20.82°
M- 13.36°
B- 18.27°
M- 11.79°
B- 16.27°
M- 10.56°
B- 14.66°
60°
M- 26.57°
B- 37.76°
M- 19.96°
B- 30.60°
M- 16.10°
B- 25.66°
M- 13.54°
B- 22.07°
M- 11.70°
B- 19.35°
M- 10.31°
B- 17.23°
M- 9.23°
B- 15.52°
65°
M- 22.91°
B- 39.86°
M- 17.07°
B- 32.19°
M- 13.71°
B- 26.95°
M- 11.50°
B- 23.16°
M- 9.93°
B- 20.29°
M- 8.74°
B- 18.06°
M- 7.82°
B- 16.26°
70°
M- 18.88°
B- 41.64°
M- 13.95°
B- 33.53°
M- 11.17°
B- 28.02°
M- 9.35°
B- 24.06°
M- 8.06°
B- 21.08°
M- 7.10°
B- 18.75°
M- 6.34°
B- 16.88°
75°
M- 14.51°
B- 43.08°
M- 10.65°
B- 34.59°
M- 8.50°
B- 28.88°
M- 7.10°
B- 24.78°
M- 6.12°
B- 21.69°
M- 5.38°
B- 19.29°
M- 4.81°
B- 17.37°
80°
M- 9.85°
B- 44.14°
M- 7.19°
B- 35.37°
M- 5.73°
B- 29.50°
M- 4.78°
B- 25.30°
M- 4.11°
B- 22.14°
M- 3.62°
B- 19.68°
M- 3.23°
B- 17.72°
85°
M- 4.98°
B- 44.78°
M- 3.62°
B- 35.84°
M- 2.88°
B- 29.87°
M- 2.40°
B- 25.61°
M- 2.07°
B- 22.41°
M- 1.82°
B- 19.92°
M- 1.62°
B- 17.93°
90°
M- 0.00°
B- 45.00°
M- 0.00°
B- 36.00°
M- 0.00°
B- 30.00°
M- 0.00°
B- 25.71°
M- 0.00°
B- 22.50°
M- 0.00°
B- 20.00°
M- 0.00°
B- 18.00°
MAINTENANCE
CLEANING
Use only mild soap and damp cloth to clean the tool.
Never let any liquid get inside the tool; never immerse
any part of the tool into a liquid.
Regularly clean the tool’s air vents with compressed dry air.
DO NOT ATTEMPT TO CLEAN BY INSERTING POINTED
OBJECTS THROUGH OPENINGS.
LUBRICATION
All of the bearings in this tool are lubricated with a
sufcient amount of high grade lubricant for the life of
the unit under normal operating conditions. Therefore,
no further lubrication is required.
12 MONTHS WARRANTY
12 MONTH LIMITED WARRANTY. EVOLUTION POWER TOOLS
RESERVES THE RIGHT TO MAKE IMPROVEMENTS AND
MODIFICATIONS TO DESIGN WITHOUT PRIOR NOTICE.
Evolution Power Tools will, within twelve (12) months from the
original date of purchase, repair or replace any goods found to
be defective in materials or workmanship, provided the product
warranty registration card has been returned to Evolution Power
Tools within thirty (30) days of purchase date. This warranty is void
if the tool being returned has been used to cut materials beyond the
recommendations in the Instruction Manual or if the saw has been
damaged by accident, neglect, or improper service. This warranty
does not apply to machines and / or components which have been
altered, changed, or modied in any way, or subjected to use beyond
recommended capacities and specications. Electrical components
are subject to respective manufacturers’ warranties. All goods
returned defective shall be returned prepaid freight to Evolution
Power Tools. Evolution Power Tools reserves the right to optionally
repair or replace it with the same or equivalent item. There is no
EC Declaration of Conformity
We: Evolution Power Tools Limited
Evolution House
New Street
  Shefeld
S20 3GH
As the supplier of the item listed below:-
Rage 3 255mm (10”) TCT Multi Purpose Sliding Mitre Saw
Part No. RAGE3255
Voltage 110 - 230V
Power 2000W
Declare, under our sole responsibility that the equipment to which
this document relates is in conformity with the following standards
or other normative documents:-
EN 60335-1:1994+A1+A2+A11–A16
EN 55014-1:2000+A1+A2
EN 55014-2:1997+A1
EN 61000-3-2:2000
EN 61000-3-3:1995+A1
EN 61000-3-11:2000
And thereby conforms to the protection requirements of
Council Directive 73/23/EC amended by 93/68/EC relating
to the Low Voltage Directive, Council Directive 98/37/EC
relating to the Machinery Directive and Council Directive
89/336/EC relating to the EMC Directive, and is compliant
with EU Directive 2002/95/EC in relation to the Restriction of
Hazardous Substances in Electrical & Electronic Equipment
(ROHS).
Guaranteed Sound Power Level: 98 dB(A)
Conformity assessment method to annex V of Directive
2000/14/EC
Relevant technical documentation kept at Evolution Power
Tools Ltd, Shefeld
Authorised by:
Mr M J Gavins
Managing Director
19
th
June 2006
06
(Year of afxation)
8 3
