EVOnet network camera - Illustrated Parts List (Plastic Dome Model)

User’s Manual
6
< Shield Case > < Bod
y
>
① IR LED ② Lens ③ Heater ④ Rotation Base
⑤ Pan Base ⑥ SD Memory Card Slot
⑦ Factory Reset Switch ⑧ Safety Wire Setscrew Hole
⑨ Wall/Ceiling Mounting Hole ⑩ Dome Cover Setscrew Hole
⑪ Bottom Cover ⑫ Input/Output Device Ports
⑬ Cable Access Hole ⑭ Tilt Adjustment Screw
Plastic Dome Model
< Dome Cover > < Shield Case >
① Side Cable Access Hole
< Bod
y
>
① IR LED
② Lens
③ Rotation Base
④ Pan Base
⑤ SD Memory Card Slot
⑥ Factory Reset Switch
⑦ Bottom Cover
⑧ Input/Output Device Ports
⑨ Cable Access Hole
⑩ Tilt Adjustment Screw
