Engine Oil
6. Place the oil pan, or other container suitable for hold-
ing engine oil, in front of the generator.
CAUTION
Generator is heavy! Obtain assistance to lift the
generator to avoid back or other bodily injury.
9. Return the unit to the upright position.
10. Remove the oil drain pipe.
11. Using a clean cloth, wipe around the drain plug area
to remove any dirt and debris.
12. iate
amount and type of new (unused) oil. (See Figure 17
for recommended oil type.)
EVO1000i
EVO2000i+
TABLE 5. Engine Oil Capacity
FIGURE 23: Oil Drain Pan
13.
FILL.
7.
FIGURE 26:
Adding Engine Oil
14. Check the oil level is up to the innermost thread of
the crankcase.
FIGURE 24:
Oil Fill Cap Removal
8. Attach the oil drain pipe (do not over tighten) and tilt
the generator allowing the oil to completely drain
into the oil pan.
FIGURE 27:
Oil Fill Measurement
FIGURE 25: Drain Oil (EVO2000i Model)
EVO1000Si / EVO2000Si / EVO2000SEi / EVO3000Si / EVO3000SEi Inverter Generator Owner’s Manual www.evopower.co.uk 19
