Cleaning Spark Arrestor Screen (EVO2000i+ Model)
6. Squeeze out excess oil.
Cleaning Spark Arrestor Screen
(EVO2000i+ Models)
WARNING
Exhaust reaches temperatures that can cause
serious burns if touched. NEVER touch hot surfaces.
7.
NOTE:
FIGURE 37: Excess Oil Removal
The generator exhaust is equipped with a spark arrestor
screen, which must be cleaned according to the
maintenance schedule (Table 3).
To clean the spark arrestor screen, you will need:
Screwdriver handle
Screwdriver universal bit
Wire brush
illustration below.
1.
Stop the generator if the engine is running. Allow to
completely cool.
FIGURE 38: Air Filter Installation - EVO1000i Model
8. Place the choke in the center position to allow it to
clear the back maintenance cover opening and
reinstall the back maintenance cover.
CAUTION
Frequent or prolonged contact with engine oil may cause
skin cancer.
• Thoroughly wash hands and any areas of skin
exposed to used oil with soap and water.
NOTE:
The engine will smoke during initial start-up if too much
2.
3.
Remove the exhaust cover and spark arrestor screws
using the Phillips end of the universal screwdriver bit.
FIGURE 39: Remove Spark Arrestor and Exhaust Cover
4. Using the standard screwdriver bit, loosen the spark
arrestor by gently working it back and forth on both
sides being careful not to bend the arrestor tabs.
5. Inspect the spark arrestor screen.
If the screen is damaged or excessively worn,
replace with a new spark arrestor.
If the screen is in good condition, clean using a
wire brush and reinstall.
NOTE:
If the spark arrestor screws appear misaligned, rotate
the spark arrestor 180 degrees.
6. Reinstall spark arrestor screws, exhaust cover, and
exhaust screws.
EVO1000Si / EVO2000Si / EVO2000SEi / EVO3000Si / EVO3000SEi Inverter Generator Owner’s Manual www.evopower.co.uk 23
