Configuration
The Configuration section lists the input signal characteristics requested by the client (e.g. Ingest
service).
Thumbnail
This section displays a JPEG thumbnail (270x180 pixels) of the incoming video signal. The thumbnail is
refreshed every second.
• When a signal is received, 'Error: No error' will be displayed in the top left corner and the thumbnail is
automatically refreshed.
• When no signal is received, 'Error. No signal' will be displayed in the top left corner and the thumbnail
will be replaced with the error message "Error. Failed to retrieve channel thumbnail".
With some early 12.x SDI engine versions, the last known image may be displayed instead of
an error message.
SDIStatus
• Error:
◦ No Error
◦ No Signal: There is no incoming video signal or the cable is disconnected
◦ Bad Signal: The signal is not in the configured format
◦ Unknown: There is no stream.
• Running: Status of the evs-sxe-sdi service.
• SyncWithRef: Indicates if the incoming video signal is genlocked.
Signal
The Signal section lists the actual characteristics of the input signal monitored by the SDI adapter card.
The following information is displayed about each signal:
• Raster:Horizontal resolution, scan mode and framerate of the video stream.
• AudioTracks: The number of audio tracks present in the SDI input signal. Tracks are counted as
individual mono tracks. Eight stereo SDI pairs are displayed as sixteen audio tracks.
• 3G Interface: Indicates if the input is connected to a 3G-SDI signal.
• LtcValid: A valid LTC (= longitudinal time code) input signal has been detected.
INSTALLATION AND CONFIGURATION MANUAL
Xeebra |6. Monitoring and Support| 39
