Storage Box underneath the Seat
There is a total of six 5MM hex head screws that
connect the storage box to the frame of the
machine. Removing these six screws will allow for
the storage box to be pulled straight up and out. If
the box is catching on the body shroud when
pulling upwards, push the side of the storage box
wall inwards on the side that has the circuit
breaker mounted. This will allow for the circuit
breaker mounting screws to clear the body shroud.
The seat does not have to be removed to be able
to remove the storage box but can be removed to
open the workspace.
Section 5 – Parts Replacement
Guide
Wear and Tear Item Replacement (Tires, Brake Pads, Bulbs, Batteries,
Back and Front Shocks, Axels, Motor and Throttle)
