eWON500™
The Transparent Gateway
ver 1.0
9/11/05
Page 12
User Guide
The displayed message can bring you the solution very simply like in the above screenshot (in this case, just
inactivate the IO server or port which uses your required resources).
Clicking on the Event Log link will display the latest events that have just occurred on your eWON500™. It
can bring you interesting information such as the frequency to which your problem occurred. Your
eWON500™ even allows you to apply a filter on the displayed information by selecting the required Event
Class, and by choosing the Reporting Level (Error, Warning or Trace). Just don’t forget to click on Update
to refresh the page when done:
However, if the displayed information don’t bring you the solution to the issue, it can be of great use to
extensively read the Technical Note explaining how to establish a gateway between your PC and your PLC
through the eWON. Finally, if there is still a doubt in your mind on how to make your configuration working,
then send a mail with a precise description from the involved topology, and the event log (events.txt) and
configuration files (config.txt and comcfg.txt) from your eWON500™ to the eWON technical support:
support@ewon.biz
.
