Fault by engaged freewheel
If the Excite is powered when you engage the freewheel lever, the status indicator will indicate fault
code 5. To erase the fault code and drive electrically please proceed as follows:
• first disengage the freewheel function (push te freewheel lever down)
• then, power off the system (this erases the fault)
• when the system is powered up the scooter is able to drive again
The Excite chair
The chair of the Excite is equipped with a number of adjustment possibilities which improves your seat
and driving comfort considerably. The entire chair can be height adjusted in a range of 10 cm in 4 teps
of 2,5 cm. This adjustment can be done by your dealer.
Adjust backrest angle
The backrest angle is stepless adjustable in a sitting position up to standard 105 degrees (picture 36).
By replacing the hex bolt on the turning point this can be increased up to 135 degrees. The backrest
can also be fully flipped forward to ease transport. On the right side of the chair (left shown on picture
36) is a lever. Pull it up and lean forward or rearward to adjust the desired backrest angle (picture 36).
As soon as you reached it you release the lever> The backrest will fixate in your position.
Picture 36
Never operate the lever when you are not in the chair. The backrest will come forward with strength.
Armrest adjustment
The armrests can be fully flipped up (picture 37). Also the angle and the armrest height are adjustable.
The armrests are fully flipped up by moving them up. he armrest angle is adjustable by the bolt on the
inner side of the armrest. You can turn this bolt further out by hand (the arm rest angle will go down) or
further in (the arm rest angle will go up). On the rear side of the arm rest tube is a turning knob. Turn it
loose and adjust the arm rest to the desired height. Fasten the knob securely.
Picture 37
