8 Technical Specifications
8.1 Environmental and Unit Specifications
SC0750 SC1000 SC2000 SC3000
Operating Temperature Range (degrees
C)
10-40C
Relative Humidity 10-80% (non-condensing)
Dimensions (mm)
(not including mounting
brackets)
Length 341
Depth 445
Height 44 67
Weight (kg) 3.9kg (8.61 lbs) 4.22kg (9.3 lbs) 6.5kg (14.3 lbs)
Input Voltage 100-240V AC 50/60Hz 200-240 AC
50/60Hz
200-220 AC
50/60Hz
220-240 AC
50/60Hz
Maximum AC input current (A) 9-4.3 12-6.5 13-9.6 15.6-13
Circuit Breaker Rating 10 13 16A
Maximum DC power (W) 750 1000 1992 2400 2700
DC output voltage 48V, +/-1V
Maximum DC current (A) 15.7 21 41.5 50 56.3
Number of DC output connectors 2 4
Certifications CE, RoHS, WEEE
Table 2 Technical Specifications
8.2 Regulatory Compliance
The SC0750/SC1000/SC2000/SC3000 System Controllers have been tested and found to comply with product
safety and electromagnetic compatibility requirements. For a complete list of tests and for certification
details, please contact your OmniCure® representative or visit www.excelitas.com/omnicure for more
details.
**WARNING**
Changes or modifications not expressly approved by Excelitas Technologies could
void the user’s authority to operate the equipment.
Product Safety:
General Requirements
IEC Equipment Class: I
Installation Category: II
Pollution Degree: 2
Requirements for MAINS cords or cord sets are contained in ANSI/UL 817 and CSA C22.2 No. 21.
Requirements for general use receptacles, attachment plugs, and similar wiring devices are contained in
ANSI/UL 498 and CSA C22.2 No. 42, CSA C22.2 No. 182.1, CSA C22.2 No. 182.2, and CSA C22.2 No. 182.3.
For Canadian and United States standards for MAINS connectors:
