OmniCure® SC- Series
UV Curing Solutions
www.excelitas.com/omnicure
Excelitas Canada Inc. 2021
All rights reserved
035-xxxxxR, rev.1
035-00539R rev 2
035-xxxxxR, rev.1
5
035-00539R rev 5
7. If the System Controller is intended to power more than one UV LED head, repeat steps 5and 6 for each
unit to be connected.
8. Plug the trailing end of the AC power cord into an AC mains outlet at the wall capable of supplying
voltage and current as per the specifications in this manual.
9. Arm the circuit breaker by pushing the breaker switch towards the AC-inlet receptacle.
10. Using the power switch on the front of the System Controller, power on the connected AC-series UV
LED equipment. When the outputs are live, a green LED status indicator on the front of the System
Controller will be lit. The internal power supply circuitry is now energized and the internal fan should
now be audible.
11. If the status indicator does not illuminate and the UV LED heads fail to power up, ensure that steps 1-9
have been followed properly.
**WARNING**
The System Controller should only be connected to a mains outlet using the style and rating of
cable provided. This regional cable is of the 3-pin variety and carries a protective earth
connection. For user safety, do not substitute this cable with any 2-pin variety.
