Example of Transmission:
Data format for RS-232 continuous transmission are as below.
1. The gross weight (+0.876 kg) shown as below, after stable: (under no tare or pre-tare
mode)
S T , G S , + 0 0 0 . 8 7 6 k g 0D 0A
HEAD , HEAD , DATA UNIT C LF
2. The net weight (-1.568lb) shows as below, after unstable: (under tare or pre-tare mode)
U S , N T , - 0 0 1 . 5 6 8 l b 0D 0A
HEAD , HEAD , DATA UNIT C LF
3. The net weight (+15 TW Catty and 6.24 tl.T), after stable: (under tare or pre-tare mode)
S T , N T , + 1 5 . 0 6 . 2 4 t l . T 0D 0A
HEAD , HEAD , DATA UNIT C LF
4. The net weight (+15 Catty and 6.24 HK Catty), after stable: (under tare or pre-tare
mode)
S T , N T , + 1 5 . 0 6 . 2 4 h k g 0D 0A
HEAD , HEAD , DATA UNIT C LF
