17
SYMPTOM: Drive belt is slipping.
1. Remove belt cover Note: Use caution around belt when cover is removed.
2. Loosen idler with adjustable wrench and tighten tensioner bolt 2-3 turns with appropriate wrench
3. Tighten idler and test belt
4. If belt still slips repeat process until belt no longer slips.
5. Reinstall belt cover.
SYMPTOM: Knocking noise or play felt in pedals/cranks.
1. Make sure pedals are tight on crank arms. Note: Left pedal is reverse threaded.
2. Make sure crank bolts are tight. If loose, tighten crank bolts to 48 ft-lbs (575 in-lbs) with 8mm hex
wrench.
3. If problem persists check if the bottom bracket bearing cups are loose. Tighten if necessary with a
bottom bracket tool and use blue Loctite 242 on threads.
4. If knocking noise still persists contact authorized service technician for replacement of bottom
bracket bearings.
This is to certify that the Exertec SP-700 bike is warranted by JK Fitness Equipment Inc. to be free of all
defects in materials and workmanship. This warranty does not apply to any defect caused by negligence,
misuse, accident, alteration, and improper maintenance.
The Exertec SP-700 Warranty assumes that the recommended service guidelines
have been followed by the customer, and covers the following:
Parts:
° Frame – 5 years
° Cranks, flywheel, handlebar, handlebar post, seat post – 2 years
° Bottom bracket cartridge assembly, pillow block bearings, tension assembly – 1 year
° Pedals – 1 year
° Seat, grip, handles, pedal straps, and brake pad – 90 days
Contact Academy Sports & Outdoor Customer Service Department (888) 922-2336 to report any
problems. When calling, please be prepared
to provide the customer service representative with the following information:
• Your name, customer number, shipping address, and telephone number
• The serial number(s) of the inoperable bike(s)
• The date(s) of purchase for the inoperable bike(s)
• Your billing address
Warranty Information
