Part No.
DESCRIPTION QTY
35 Hex nuts 3
36 Washer 1
37 Hex flange nut 1
38
Cross umbrella head self-tapping
screws 8
39 Casing 1
40 High cap 1
41 Spring 1
42 L-shaped wrench 1
43 Integrated wrench 1
44 Hollow plug 3
45 Crank plug 2
46 POP-PIN 3
47 End cap 1
48 End cap 1
49 End cap 4
50 End cap 1
51 Adjustable foot pad 4
52 Pulley 2
53 Cover cushion 2
54 Pull handle casing 1
55 Water bottle 1
56 Inner side cover 1
57 Outer side Cover 1
58 Front cover 1
59 Idler wheel 2
60 Brake 2
61 Left pedal 1
62 Right pedal 1
63 Seat 1
64 Belt 1
*Note that the main frame, including the flywheel, belt cover, and the water bottle
(Part list No. 1, 8-18, 20-21, 26-27, 29-45, 47-50, 52-60, 64) are pre-assembled portion of the bike.
