Page #20 background image
15
5.2 FRONT FRAME GROUP
Item
Part No.
Description
Qty.
1 1-303334 Washer, Spring Disk 5/16 ......................2
2 1-513810 Bushing, Flanged...................................4
3 1-543508 Cup, Bearing Tapered Roller .................4
4 1-543509 Cone, Bearing Tapered Roller................4
5 1-543511 Seal, Grease..........................................2
6 1-633508 Washer, Spring Disk..............................6
7 1-811010 Plug .......................................................2
8Q 103-3729-01 Wld, Deck Pivot (RH).............................1
9Q 103-3732-01 Wld, Deck Pivot (LH) .............................1
10 103-3772 Plug, Spring Adjuster .............................2
11 103-3773 Shaft, Spring Adjustment .......................2
12 103-4017 Spacer, Front Caster..............................2
13 103-4118 Wld, Deck Lock (LH)..............................1
14 103-4119 Wld, Deck Lock (RH) .............................1
15 103-9482 Asm, Deck Lift Handle W/Decal.............1
16 103-4284 Wld, Spring Tensioner ...........................2
17 103-4285 Mount, Deck Lift Spring..........................2
18 103-4588 Bearing, Roller Straight..........................2
19 103-4882 Cap, Grease ..........................................2
20 103-7353 Pin, Cut Height.......................................2
21 103-7436 Bushing, Deck Support ..........................2
22 103-7448 E-Ring....................................................2
23 103-7865 Wld, Spring Tube...................................2
24 103-7971 Cover, Deck Spring................................2
25 103-8504 Decal, Navigator Model..........................1
26 103-8667 Pad, Anti Skid (42”)................................1
103-8630 Pad, Anti Skid (48”)................................1
Item
Part No.
Description
Qty.
27 103-8797 Decal, Folding Deck............................... 2
28 103-8798 Decal, Danger........................................ 1
29 103-8799 Decal, Spring......................................... 2
30 302-19 Zerk, 1/4-28 Str......................................4
31 302-61 Zerk, 45° 1/4-28..................................... 4
32 322-4 Screw, HH 5/16-18 x 7/8........................ 2
33 325-38 Screw, HH 1/2-13 x 4 3/4....................... 2
34 3218-3 Nut, Jam 3/8-16..................................... 2
35 3243-5 Setscrew, SQH 3/8-16 x 1 ..................... 2
36 3256-28 Washer, 3/4 SAE................................... 2
37 3296-29 Nut, Nyloc 5/16-18................................. 2
38 3296-39 Nut, Nyloc 3/8-16................................... 4
39 3296-45 Nut, Nyloc 1/2-13................................... 2
40 3296-51 Nut, Nyloc 3/4-10................................... 2
41 32120-33 Ring, Retaining...................................... 2
42 32121-3 Rollpin 3/16 x 3/4...................................2
43 614672 Screw, Shoulder 3/8-16 x 1.295.............2
44 103-3655-01 Wld, Fork & Spindle...............................2
45 103-4324 Asm, Wheel & Tire 8x3.00-4 Sp.............2
46V 103-9481 Asm, Front Frame W/Decals (42")......... 1
V
103-9480 Asm, Front Frame W/Decals (48")......... 1
47 103-4281 Spring, Extension................................... 2
48 103-9495 Asm, Caster Wheel W/Axle ...................1
49O 103-4280 Asm, Spring Lift Assist...........................2
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
V Includes frame weldment plus items #7, #13, #14, #19, #21, #25, #37, #38, and Decals.
Q Include zerk, item #30.
O Includes (2) nyloc nuts, item #38.
