Exmark LAZER Z X Series User Manual

Operation
Figure5
1.Neutrallockposition
(handlesout)
4.Forward
2.Neutraloperateposition
(handlesin)
5.Neutral(operate)
3.FrontofUnit
6.Reverse
ChokeControl(AllUnitsExcept
KohlerEFI)
Locatedonrightconsole(blacklever)(seeFigure6).
Thechokeisusedtoaidinstartingacoldengine.
Movingthechokeleverforwardwillputthechokein
the“ON”positionandmovingthechokelevertothe
rear,tothedetent,willputthechokeinthe“OFF”
position.DoNotrunawarmenginewithchokein
the“ON”position.
Figure6
RightConsole
1.Fuses
4.PTOengagementswitch
2.Messagedisplay5.Throttle
3.Ignitionswitch
6.Choke
ThrottleControl
(AllUnitsExceptEFIREDEquipped
Units)
Locatedonrightconsole(redlever)(seeFigure6).
Thethrottleisusedtocontrolenginespeed.Moving
thethrottleleverforwardwillincreaseenginespeed
andmovingthethrottlelevertotherearwilldecrease
enginespeed.Movingthethrottleforwardintothe
detentisfullthrottle.
ThrottleControlwithClutchSaver
(EFIREDEquippedUnits)
Locatedonrightconsole.
Thethreepositionthrottleswitchisusedtocontrol
enginespeed(Figure7).
Whentheswitchisinthemiddleposition(Efcient
mode):
•Pressingdownonthefrontoftheswitchwill
placeitinMaxmode.
•Pressingdownontherearoftheswitchwillplace
itinLowmode.
27

Exmark LAZER Z X Series Specifications

General

Engine Type	V-Twin
Transmission	Hydrostatic
Engine Brand	Kawasaki
Cutting Width	60 inches
Deck Construction	Fabricated steel
Seat Type	High-back with armrests
Category	Commercial
Engine	Kawasaki
Deck Type	Fabricated
Weight	1, 495 lbs
Warranty	5-year limited
