Exmark LAZER Z X Series User Manual

Operation
Seethedecalonthesideofthedeckliftplatefor
cutheights.
6.Pushthedeckliftpedal,releasethetransportlock
andallowthedecktolowertothecuttingheight.
AdjustingtheAnti-ScalpRollers
Itisrecommendedtochangetheanti-scalproller
position,whentheheightofcuthaschanged.
1.Stopthemachineandmovethemotioncontrol
leversoutwardtotheneutrallockedposition.
2.DisengagethePTO.
3.Engagetheparkbrake.
4.Stoptheengine,removethekeyandwaitforall
movingpartstostop.
5.Afteradjustingtheheightofcut,adjustthe
anti-scalprollersbyremovingthemounting
hardware.
6.Placetherollersinoneofthepositionsshown
(Figure18).Rollerswillmaintain3/4inch(19
mm)clearancetothegroundtominimizegouging
androllerwearordamage.
Figure18
Forcuttingheightsabove3.5inches(90mm)usethe
bottomhole.Therollerswillstillbeeffectiveagainst
scalping.
1.Anti-scalproller
mountingbracket
2.Cuttingheight
ForMaximumDeckFlotation,placetherollers
oneholepositionlower.Rollersshouldmaintain
1/4inch(6.4mm)clearancetotheground.Do
Notadjusttherollerstosupportthedeck.
7.Reinstallthemountinghardware.
•SideDischargeUnits:
A.Besuretherollerboltsareinstalledwith
thespringdiscwasherbetweenthehead
oftheboltandthemountingbracket(see
Figure19).
B.Torquethe3/8nylocnutto50–55ft-lb
(68-75N-m).
Figure19
1.3/8-16X33/4Grade8
bolt
3.Frontrightanti-scalp
bracketshown
2.Springdiscwasher
(conetowardsbolthead)
4.3/8nyloc-torqueto50-55
ft-lb(68-75N-m)
•RearDischargeUnits:
Torquethe3/8nylocnutto30-35ft-lb(41-47
N-m)(seeFigure20).
Figure20
Note:Thefootoperateddeckliftassistlevercanbe
usedtomomentarilyliftthedecktoclearobjects.Be
surethatPTOisdisengaged.
35

Exmark LAZER Z X Series Specifications

General

Engine Type	V-Twin
Transmission	Hydrostatic
Engine Brand	Kawasaki
Cutting Width	60 inches
Deck Construction	Fabricated steel
Seat Type	High-back with armrests
Category	Commercial
Engine	Kawasaki
Deck Type	Fabricated
Weight	1, 495 lbs
Warranty	5-year limited
