Maintenance
7.Releasethetransportlockandallowthedeckto
lowertothecuttingheight.
8.Raisethedischargedeector(sidedischargeunits
only).
9.Measurefromthelevelsurfacetothefronttipof
thecenterblade.Themeasurementshouldread
3inches(7.6cm).
Note:Inmostconditions,thebacktipsonthe
sidebladesshouldbeadjusted:
SideDischargeUnits:1/4inch(6.4mm)higher
thanthefront.
RearDischargeUnits:tobelevelwiththefront.
Figure37
1.SideDischarge:31/4inches(8.3cm)
RearDischarge:3inches(7.6cm)
2.Backbladetip
3.Frontbladetip
4.3inches(7.6cm)
5.Levelsurface
10.Adjusttheheight—toincrease,turnthe
adjusterscrewclockwise;todecrease,turn
counterclockwise.
•X-Series:
Loosenthejamnutsonthetopofeachdeck
adjuster.Finetunetheadjusteronthefront
deckliftassemblybyturningittoget3inch
(7.6cm)height(seeFigure38).
Figure38
1.Adjusterlink3.Adjuster
2.Jamnut
•SandE-Series:
Finetunethefrontdeckliftassemblyby
turningtheadjusterscrewuntilitreachesthe
3inch(7.6cm)height(seeFigure39).
Figure39
1.Adjusterscrew2.Jamnut
11.Measurethebacktipheight.Finetunerear
adjustersasrequired;thesinglepointadjustment
canbeutilizedtogainmoreadjustment.
51

Exmark LAZER Z X Series Specifications

General

Engine Type	V-Twin
Transmission	Hydrostatic
Engine Brand	Kawasaki
Cutting Width	60 inches
Deck Construction	Fabricated steel
Seat Type	High-back with armrests
Category	Commercial
Engine	Kawasaki
Deck Type	Fabricated
Weight	1, 495 lbs
Warranty	5-year limited
