Exmark Lazer Z XS User Manual

Maintenance
Figure19
1.Leverdown
(disengaged)
6.Removepintoadjust
rodlengthforadditional
brakeadjustment
2.Leverup(engaged)
7.Trunnionroller
3.Nylocnutbelowtrunnion
roller
8.Springretainerbracket
4.Nylocnutbelowspring
9.213/16inches(7.1cm)
5.1/8to3/16inch(3.2to
4.8mm)
10.Jamnutabovetrunnion
roller
BrakeAdjustment
1.Checkforbrakelink213/16inches(7.1cm)
measurementasdescribedintheBrakeLink
Adjustmentsection.
2.Engagethebrakelever(leverup).Thespace
betweenthebrakespringbracketandthenyloc
nutunderthespringshouldmeasure1/8inchto
3/16inch(3.2–4.8mm).
3.Ifadjustmentisnecessary,loosenjamnutabove
thetrunnionroller.Adjustthenylocnutunder
thetrunnionrolleruntildistancelistedabove
existsbetweenthespringretainerbracketandthe
adjacentnylocnut.Tightenthejamnutabove
thetrunnionroller.
4.Ifthecorrectgapcannolongerbeachieved
becausethereisnoclearancebetweenthenyloc
nutbelowthespringandthejamnutabove
thetrunnionortherearenothreadsleftonthe
bottomnylocnut,thelengthofthebrakerodcan
beadjusted.Removeapinfromayokeateither
endofthebrakerodandlengthen(orshorten)the
brakeroduntilthecorrectgapcanbeachievedby
followingsteps2and3.
ElectricClutchAdjustment
Noadjustmentnecessary.
ReverseIndicator
Adjustment
1.Stopengine,waitforallmovingpartstostop,and
removekey.Engageparkingbrake.
2.Unhookseatlatchandtiltseatforward.
3.Beginwitheithertheleftorrightmotioncontrol
lever.Movelevertotheneutralpositionandpull
leverbackuntiltheclevispin(onarmbelowpivot
shaft)contactstheendoftheslot(justbeginning
toputpressureonspring).(Figure20).
4.Checkwhereleverisrelativetonotchinconsole
(shouldbecenteredallowinglevertopivot
outwardtotheneutrallockposition).
5.Ifadjustmentisneeded,loosenthenutagainstthe
yokeandwhileapplyingslightrearwardpressure
onthemotioncontrollever,turntheheadofthe
adjustmentboltintheappropriatedirectionuntil
leveriscentered(keepingrearwardpressureon
theleverwillkeepthepinattheendoftheslot
andallowtheadjustmentbolttomovethelever
totheappropriateposition).Tightenlocknut.
6.Repeatonoppositesideofunit.
Figure20
1.Turnbolthere4.Yoke
2.Levercenteredinnotch5.Loosenhere
3.Endofslot
6.Reverseindicator
41
