32” and 36” MOWER DECK
3
Item Part No. Description Qty.
1 103-2312 Deck (103-2307-01) W/Decals
& Dogleg(36") ........................................1
103-2313 Deck (103-2301-01) W/Decals &
Dogleg (32")...........................................1
2 1-302189-01 Wld, Dogleg Baffle ................................. 1
3 322-2 Screw, HH 5/16-18 x 5/8 ........................7
4 32128-20 Nut, Whizlock 5/16-18 ............................22
5 103-3600 Asm, Engagement Arm W/Bushings ......1
6 302-52 Zerk, 1/8 NPT Straight ...........................2
7 302-19 Zerk, 1/4-28 Straight .............................. 1
8 1-323385 Knob, Belt Cover....................................4
9 1-809020 Quick Pin, 10" Caster.............................2
10 3296-29 Nut, Nyloc 5/16-18 .................................3
11 323-8 Screw, HH 3/8-16 x 1 1/2 .......................8
12 3290-357 Nut, Whizlock 3/8-16 ..............................16
13 1-323748 Ring, Push-On 7/16................................1
14 98-5975 Washer, Spring Disc 3/8......................... 9
15 1-808280 Pin, Clevis 5/16 x 1 ................................1
16 1-303105 Yoke ......................................................1
17 1-806003 Hairpin, Cotter #2...................................3
18 32151-103 E-Ring....................................................1
19 702809 Screw, HH 3/8-16 x 1 7/8 ....................... 1
20 103-6584 Blade, Notched (36").............................. 2
103-6582 Blade, Mulching (36").............................2
103-6580 Blade, Low Lift (36")...............................2
103-1578 Blade, Solid (36") ...................................2
103-6337 Blade, Extreme (36”) .............................. 2
103-6583 Blade, Notched (32").............................. 2
103-6581 Blade, Mulching (32) .............................. 2
103-2507 Blade, Low Lift (32")...............................2
103-1577 Blade, Solid (32") ...................................2
103-6336 Blade, Extreme (32”) .............................. 2
21 1-513338 Washer, Special.....................................2
22 3253-7 Washer, Lock 1/2 ................................... 2
23 3217-9 Nut, Hex 1/2-13...................................... 2
24 325-20 Screw, HH 1/2-13 x 6 .............................2
25 1-303352 Washer, Spindle..................................... 1
26 32120-35 E-Ring....................................................1
27 1-323733 Drive Belt (To Blades) 36" Model ...........1
1-323734 Drive Belt (To Blades) 32" Model ...........1
28 1-803310 Setscrew, 5/16-18 x 3/8.......................... 2
29 322-6 Screw, HH 5/16-18 x 1 1/4 ..................... 9
30 3256-23 Washer, 5/16 SAE.................................. 1
31 1-303537 Stud, Belt Shield (Short)......................... 2
32 1-303536 Stud, Belt Shield (Long) .........................2
33 1-324208 Shield (1-302213-01) W/Decals, 36" ......1
1-324194 Shield (1-322149-01) W/Decals, 32" ......1
34 1-323417 Washer, Belt Cover Mount ..................... 4
35 1-322145-01 Wld, Caster Fork ....................................2
36 103-1236 Asm, Caster Wheel Assembly................2
Item Part No. Description Qty.
37 1-302233-01 Chute..................................................... 1
38 3296-56 Nut, Nyloc 1/4-20 Thin ........................... 1
39 1-323729 Bearing .................................................. 2
40 323-4 Screw, HH 3/8-16 x 3/4.......................... 8
41 1-603843 Pulley, Idler............................................ 1
42■ 103-8387 Asm, Cutter Housing Complete.............. 2
43 322-5 Screw, HH 5/16-18 x 1........................... 2
44 103-8280 Asm, Cutter Housing.............................. 2
45 302-61 Zerk, 45° 1/4-28..................................... 2
46 103-2535 Spacer ................................................... 2
47 1-403179 Tube, Pivot ............................................ 1
48 1-303314 Spacer, 10" Caster................................. 8
49 1-323529 Tube, Spindle ........................................ 2
50 321-4 Screw, HH 1/4-20 x 3/4.......................... 2
51 1-303514 Flange , Thrust Bearing ......................... 4
52 1-323339 Washer .................................................. 2
53 1-403183 Sheave, Blade Driven ............................ 2
54 3219-6 Nut, Hex 5/8-18 UNF ............................. 2
55 1-800861 Screw, HH 5/8-18 x 8............................ 2
56 1-807267 Key, 1/4 x 3/16 x 1 1/4 ........................... 2
57 1-323539 Spacer, Blade Drive............................... 8
58 1-513208 Washer, Spring Disc 5/8 ........................ 2
59 1-303434 Bushing, Engagement............................ 1
60 1-303348 Eye Bolt (Left Hand Thread) .................. 1
61 1-303236 Turnbuckle Body.................................... 1
62 1-303238 Eye Bolt (Right Hand Thread) ................ 1
63 1-322235 Arm, Assist ............................................ 1
64 322-10 Screw, HH 5/16-18 x 2........................... 1
65 1-323303 Linkage, Assist Arm ............................... 1
66 103-1238 Asm , Caster/Mount Complete............... 2
103-2281 Asm, Caster/Mnt Complete, Weighted ... 2
67 1-302203 Asm, Caster Whl Support W/Bearings ... 2
103-2296 Asm, Caster Wheel Support
W/Bearings, Weighted ........................... 2
68 1-302194-01 Wld, Caster Wheel Support.................... 2
103-2297-01 Wld, Caster Wheel Support, Weighted... 2
69 1-303334 Washer, Spring Disc 5/16 ..................... 9
70 1-324372 Asm, Pad/Spring.................................... 1
71 103-1330 Guard, Bearing Top ............................... 2
72 3256-3 Washer, 5/16 Std................................... 1
73 1-323715 Rod, Brake 36" ...................................... 1
1-323718 Rod, Brake 32" ...................................... 1
74 1-323071 Spring .................................................... 1
75 1-323747 Spring, Compression ............................. 1
76 1-323746 Spacer, Flanged .................................... 1
77 3296-42 Nut, Nyloc 1/4-20................................... 2
78 1-513547 Spacer, Front Caster.............................. 2
79 103-2171 Kit, Tire & Wheel Asm W/ Spacer .......... 2
80 1-513809 Roller Bearing........................................ 1
81 1-513810 Bushing ................................................. 4
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews.
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N’s MK322(32”) or MK362(36”)
Models with ECS handles only.
Models with Standard pistol grip handles only.
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-sieze) between the spindles & bearings
and spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.
■ Does not include items #4, #29, & #69
