Maintenance
conditions)(Kawasaki
engine).
Checktheaircleanerdailyorbeforestartingthe
engine.Checkforabuildupofdirtanddebrisaround
theaircleanersystem.Keepthisareaclean.Also
checkforlooseordamagedcomponents.Replaceall
bentordamagedaircleanercomponents.
Note:Operatingtheenginewithlooseordamaged
aircleanercomponentscouldallowunlteredairinto
theenginecausingprematurewearandfailure.
Note:Servicetheaircleanermoreoftenunder
extremelydusty,dirtyconditions.
RemovingtheElements:
1.Parkthemachineonalevelsurface,disengagethe
bladecontrolswitch,movethemotioncontrol
leverstothebrakeposition,stoptheengine,
removethekey,andwaituntilallmovingparts
stopbeforeleavingtheoperatingposition.
2.Cleanaroundtheaircleanercovertopreventdirt
fromgettingintotheengineandcausingdamage.
3.Liftthecover,loosenthehoseclamp,andremove
thepaperelement.
g207139
Figure26
1.Cover
3.Hoseclamp
2.Paperelement
CleaningthePaperElement:
1.Lightlytaptheelementonaatsurfacetoremove
dustanddirt.
2.Inspecttheelementfortears,anoilylm,and
damagetotheseal.
Important:Donotcleanthepaperelement
withpressurizedairorliquids,suchas
solvent,gas,orkerosene.Replacethepaper
elementifitisdamagedorcannotbecleaned
thoroughly.
CheckingtheEngineOil
ServiceInterval:Beforeeachuseordaily
Important:Donotoverllthecrankcasewithoil
andruntheengine;enginedamagemayresult.
1.Parkthemachineonalevelsurface,disengage
thebladecontrolswitch,stoptheengine,engage
parkingbrake,andremovethekey.
2.Makesuretheengineisstopped,level,andiscool
sotheoilhashadtimetodrainintothesump.
3.Tokeepdirt,grassclippings,etc.,outof
theengine,cleantheareaaroundtheoilll
cap/dipstickbeforeremovingit.
4.Checktheengineoillevel.
40

Exmark Radius S Series Specifications

General

Engine Brand	Kawasaki
Cutting Width	52 inches
Transmission	Hydrostatic
Deck Construction	Fabricated
Deck Material	10-gauge steel
Engine Type	4-cycle
Drive Type	Rear-wheel drive
Speed	8 mph
Spindle Material	Aluminum
Deck Lift System	Foot-operated
