Exmark Radius X Series User Manual

Operation
themachinehastobepushedbyhand,thevalves
mustbeinthe“released”position(seeFigure8).
g035062
Figure8
1.Frontofthemachine
2.Rotatebypassreleaseknobcounterclockwisetoloosen
3.Leverpositionforoperatingthemachine
4.Pullleverinthisdirectiontopushthemachine
5.Leverpositionforpushingthemachine
6.Rotatebypassreleaseknobclockwisetotighten
7.Engine
8.Releaselever
Toreleasethedrivesystem(seeitem1inFigure8),
loosentheknobbyturningcounterclockwise.Then
pullthereleaseleverontheundersideofmachine
towardsthebackofthemachineandretightenthe
knobtoholdthereleaseleverbackinthereleased
state.Repeatthisoneachsideofthemachine.
Releasetheparkingbrake.Themachineisnowable
tobepushedbyhand.
Toresetthedrivesystem(seeitem2inFigure8),
loosentheknobbyturningcounterclockwise.Then
pushthereleaseleverontheundersideofmachine
towardsthefrontofthemachineandretightenthe
knobtoholdthereleaseleverintheoperatingstate.
Repeatthisoneachsideofthemachine.
DoNottowmachine.
PTOEngagementSwitch
Locatedonrightconsole(seeFigure5).
Switchmustbepulledout(up)toengagetheblades.
Switchispushedintodisengagetheblades.
DeckLiftPedal
Locatedattherightfrontcorneroftheoorpan.
Pushthepedalforwardwithyourfoottoraisethe
cuttingdeck.Allowthepedaltomoverearwardto
lowerthecuttingdecktothecutheightthathasbeen
set.
g035063
Figure9
1.Transportlockknob
3.Heightofcutdecal
2.Heightadjustmentpin
4.Deckfootpedal
TransportLock
LocatedonRHconsoleinfrontofthemotion
controllever(seeFigure9).
Thetransportlatchingmechanismwillautomatically
engagewhenthedeckisraisedtothetransport
position.Toreleasethedeckfromthetransport
position:pushthefootpedaltoremovetheload
fromthetransportlatchingmechanism,pullupon
thetransportlockknob,andletthepedalcomeback
tolowerthedeckdowntothedesiredcutheight.
21

Exmark Radius X Series Specifications

General

Engine Brand	Kawasaki
Deck Construction	Fabricated
Deck Material	10-gauge steel
Engine Type	V-Twin
Drive Type	Rear-wheel drive
Turning Radius	Zero-turn
Cutting Width	60 inches
Transmission	Hydro-Gear ZT3400
Spindle Type	Aluminum
Speed	Up to 10 mph
