Exmark Radius X Series User Manual

Maintenance
g260622
Figure44
1.Aircleanerbody3.Latch
2.Filter4.Aircleanercover
3.Cleantheinsideoftheaircleanercoverwith
compressedair.
4.Gentlyslidethelteroutoftheair-cleanerbody.
Note:Avoidknockingthelterintothesideof
thebody.
5.Inspectthelterfordamagebylookingintothe
lterwhileshiningabrightlightontheoutside
ofthelter.
Note:Holesinthelterappearasbrightspots.
Ifthelterisdamaged,discardit.
ServicingtheAirCleanerwith
Non-CanisterStyleAirFilter
ServiceInterval:Every100hours/Yearly
(whichevercomes
rst)—Servicetheair
cleanerpaperelement
(moreoftenindusty,
dirtyconditions)(Exmark
engine).
Every200hours/Every2
years(whichevercomes
rst)—Replacetheair
cleanerpaperelement
(moreoftenindusty,
dirtyconditions)(Exmark
engine).
Every25hours/Monthly
(whichevercomes
rst)—Cleantheair
cleanerfoamelement
(moreoftenindusty,
dirtyconditions)(Exmark
engine).
Every100hours/Yearly
(whichevercomes
rst)—Replacetheair
cleanerfoamelement
(moreoftenindusty,
dirtyconditions)(Exmark
engine).
Checktheaircleanerdailyorbeforestartingthe
engine.Checkforabuildupofdirtanddebrisaround
theaircleanersystem.Keepthisareaclean.Also
checkforlooseordamagedcomponents.Replaceall
bentordamagedaircleanercomponents.
Note:Operatingtheenginewithlooseordamaged
aircleanercomponentscouldallowunlteredairinto
theenginecausingprematurewearandfailure.
Note:Servicetheaircleanermoreoftenunder
extremelydusty,dirtyconditions.
RemovingtheElements:
1.Parkthemachineonalevelsurface,disengagethe
bladecontrolswitch,movethemotioncontrol
leverstothebrakeposition,stoptheengine,
removethekey,andwaituntilallmovingparts
stopbeforeleavingtheoperatingposition.
2.Cleanaroundtheaircleanercovertopreventdirt
fromgettingintotheengineandcausingdamage.
3.Liftthecoverandrotatetheair-cleanerassembly
outoftheengine(seeFigure45andFigure46).
g027800
Figure45
49

Exmark Radius X Series Specifications

General

Engine Brand	Kawasaki
Deck Construction	Fabricated
Deck Material	10-gauge steel
Engine Type	V-Twin
Drive Type	Rear-wheel drive
Turning Radius	Zero-turn
Cutting Width	60 inches
Transmission	Hydro-Gear ZT3400
Spindle Type	Aluminum
Speed	Up to 10 mph
