Operation
ProductOverview
Figure3
1.Platform
4.Enginecontrols
2.Parkbrakeknob5.Fuelcap
3.Motioncontrollevers
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Controls
MotionControlLevers
Themotioncontrollevers,locatedoneachsideofthe
topconsole,controltheforwardandreversemotion
ofthemachine.
Movingtheleversforwardorbackwardturns
thewheelonthesamesideforwardorreverse
respectively.Wheelspeedisproportionaltothe
amounttheleverismoved.
Important:Thetinesarerotatingwhenthe
motioncontrolleversaremovedoutofthe
neutralposition.
Figure4
1.LHMotioncontrollever5.Forward
2.RHMotioncontrollever6.Neutral
3.Frontreferencebar
7.Reverse
4.Frontofunit
ChokeControl
Locatedonthecontrolconsole(blacklever)(see
Figure5).
Thechokeisusedtoaidinstartingacoldengine.
Movingthechokeleverforwardwillputthechokein
the“ON”positionandmovingthechokelevertothe
rear,tothedetent,willputthechokeinthe“OFF”
position.DoNotrunawarmenginewithchokein
the“ON”position.
