Exmark VIKING HYDRO - Page 2

LiteraturePack
Manual,Operator's
Manual,EngineOperator's
UncratingtheUnit
1.Leavingtheunitonthepallet,placetheupperhandle
assemblyandthefueltankattherearofthemachine.
Placethecastersatthefrontoftheunit.
2.Placealengthof4inchx4inch(10cmx10cm)
blockbetweenthefrontofthemowerdeckandthe
pallet.
3.Removetheboltbagfromunderthemowerdeck
beltshield.
4.Refertothepartsmanualtohelpyouidentifyand
locatethepartsandtheirproperposition.
InstallingtheFrontCasterWheels
Installthecasterstothefrontofthedeckusingeight
3/8-16x3/4inchboltsandeight3/8inchwhizlock
nuts.Tightenthelowerfourboltsrst,thenthetopfour.
InstallingtheFuelTank
1.Installthefueltankontopofthefueltanksupport.
Secureeachsideofthetankwithaclamp,5/16-18x
2inchscrew ,washer,and5/16inchnylocnut.
2.Attachthefuelsupplyhosetothebottomtanktting
andsecurewiththeclampprovided.
3.Attachthepurgehosefromtheteeontheengine
(canisteronCAunits)tothetopttingofthefuel
tankasshowninFigure1.Pressthehoseintothe
slotonthetanktoretainit.
Figure1
1.Attachpurgehosetotoptting
InstallingtheHandleAssembly
1.Positionthelowerendofthehandleassemblyon
theoutsideoftheupperrearsectionofthefueltank
andhandlesupport.
2.Installfour3/8-16x1inchbolts,fourspringdisk
washersfromtheoutsidein.Secureusingfour
3/8-16whizlocknutsontheinsideofeachhandle
supportandtightenuntilthespringdiskwashersare
at(
Figure2).
Note:Besuretheconeofthespringdiskwasheris
againsttheheadofthebolt.
Figure2
1.Frontoftheunit
3.Upperhandle
2.Upperhandlemounting
tab
AttachingtheThrottleCable
1.Routethethrottlecablealongtherightsideofthe
upperhandle,underthefueltanksupport,and
positionthecableontheleftsideoftheengine.
2.Positionthethrottlecontrollever(locatedonthe
console)inthefullthrottleposition.Youwillfeela
detentwhenthethrottleleverispushedtowardsthe
upperendoftheslot.
3.Attachtheinnerwireofthethrottlecabletothetop
holeinthethrottlecontrolleverasshowninFigure3.
4.Loosentheclamp,installthethrottlecableonthe
bottomsideoftheclamp,andpullonthecableto
movethethrottlelinkagetothefullthrottleposition.
Tightenthecableclampscrew .
2
