- 9 -
2. SPECIFICATIONS
2.1 MODEL NUMBER:
Serial Nos. 320,000 & Higher: VH3215KCC; VH3615KAC; VH4815KAC
2.2 ENGINE
2.2.1 Engine Specifications: See your Engine Owner's Manual.
2.2.2 3600 RPM (No Load).
2.3 FUEL SYSTEM
2.3.1 Capacity: 5.0 gal. (18.9 L.)
2.3.2 Type of Fuel: Regular unleaded gasoline, 87 octane or higher. In countries
using the research method, it should be a 90 octane minimum.
2.3.3 Fuel Filter: Replaceable in-line
2.3.4 Fuel Shut-Off Valve: 1/4 turn
2.4 SAFETY INTERLOCK SYSTEM
Operator must have speed control lever in neutral and PTO disengaged to start
engine. Release of OPC levers will cause the engine to stop if speed control lever is
not in neutral and/or PTO is engaged.
2.5 STEERING/BRAKE CONTROL:
Fingertip drive control levers provide independent speed control, braking and neutral to
each drive wheel for moving forward or reverse, stopping and power turning.
2.6 TRANSMISSION:
Twin Hydrostatic Drive
2.6.1 Two Hydro Gear BDP-10L series variable displacement pumps independently
coupled to two high efficiency Parker/Ross wheel drive motors.
2.6.2 Hydraulic Filter is replaceable cartridge type.
P/N 1-513211: 10 microns, 18 psi bypass (Summer use above 32°
F (0° C))
P/N 1-523541: 40 microns, 18 psi bypass (Winter use below 32°
F (0° C))
2.6.3 Speed Range: Forward 0 - 6.2 mph (10.0 km/h)
Reverse 0 - 2.2 mph (3.5 km/h)
2.7 WHEEL DRIVE SYSTEM:
Drive wheels are direct coupled to Parker/Ross wheel drive motors with 1.0" (25.4 mm)
tapered shaft.
2.8 TIRES
Drive Front Caster
32” Deck 36” & 48“ Deck All decks
Pneumatic (Air-Filled) Pneumatic (Air-Filled) Semi-Pneumatic
Size 4.8/4.0-8 16 x 6.50-8 9 x 3.50-4
Quantity 2 2 2
Tread Turf Saver Turf Master Smooth
Ply Rating 2 4
Pressure 14 psi (97 kPa) 14 psi (97 kPa)
2.9 DECK
2.9.1 Cutting Width:
Model 32 in...............................................31.75 in. (80.7 cm)
Model 36 in...............................................35.38 in. (89.9 cm)
Model 48 in...............................................47.24 in. (120.0 cm)
