Exor eTOP310 - Dimensions

14
MANUGENETOP3xx - Version 2.00
© 2018 EXOR International S.p.A. - Subject to change without notice
4.1 Dimensions
4 Technical Data
MODEL A B C
D E F
eTOP306 187mm/7.36” 147mm/5.79” 176mm/6.90” 136mm/5.35” 45mm/1.77” 4mm/0.16”
eTOP307 187mm/7.36” 147mm/5.79” 176mm/6.90” 136mm/5.35” 45mm/1.77” 4mm/0.16”
eTOP308 232mm/9.13” 187mm/7.36” 221mm/8.70” 176mm/6.90” 42mm/1.65” 4mm/0.16”
eTOP310 287mm/11.30” 232mm/9.13” 276mm/10.86” 221mm/8.70” 42mm/1.65” 4mm/0.16”
eTOP312 337mm/13.26” 267mm/10.51” 326mm/9.30” 256mm/10.1” 42mm/1.65” 4mm/0.16”
eTOP313 337mm/13.26” 267mm/10.51” 326mm/9.30” 256mm/10.1” 42mm/1.65” 4mm/0.16”
eTOP315 392mm/15.43” 307mm/12.1” 381mm/15” 296mm/11.65” 46mm/1.82” 4mm/0.16”
