Exor eTOP310 - eTOP Series 300 Configuration Mode

25
MANUGENETOP3xx - Version 2.00
© 2018 EXOR International S.p.A. - Subject to change without notice
ENTER shows the type and version of the communication driver stored in the unit (if any) and boot
FW version.
ENTER 2 s returns to Operation Mode if a valid communication driver and a valid project are stored in
the unit (the key must be pressed for 2 seconds).
CLEAR 2 s Call standard touchscreen calibration procedure
 2 s Update rmware
 2 s Erase Static RAM (Password and Recipe reset)
 2 s Shows memory menu
To change the panel IP address, Ethernet GMT and DST settings: touch the item you want to change.
12.1 Operation Mode/Page Mode
To recall the Conguration Mode, touch the screen in an area where no active touch areas have been
dened and hold for 2 seconds. The value of 2 seconds can be changed with Designer on disabled
requiring the use of a touch button programmed with the specic enter conguration mode macro.
Command Menu
 select up
 select down
 select left
 select right
ENTER activate selection
CLEAR return to Page Mode
System Menu
 select up
 select down
 activate selection
 activate selection
ENTER return to Page Mode when EXT is selected
CLEAR return to Page Mode
12 Conguration Mode
