23
MANUGENETOP3xx - Version 2.00
© 2018 EXOR International S.p.A. - Subject to change without notice
The equipment must be cleaned only with a soft cloth and neutral soap product. Do not use solvents.
Panels must be programmed with the programming package Designer.
To program a panel you will have to connect the panel to a personal computer running Designer software
package; the panel must be in Conguration mode to be programmed. Use the cable CA253 to connect
the panel to a personal computer.
The software package Designer is a Windows
TM
application and must be properly installed. The Win-
dows
TM
environment is not included in the software package Designer and must already be installed on
the personal computer.
The software package can use either the communication ports COM1 or COM2 on the personal computer.
Check that the Designer program is correctly congured to comunicate with the communication port to
which the cable attached.
The communication parameters between the panel and the personal computer are:
speed: 9600 (models PC/Printer Port sup. also speeds of 19200 and 38400 baud )
parity: none
stop bit: 1
The Designer software defaults to the correct parameters.
The version of the Designer being used must be compatible with the rmware version of the panel to be
programmed. Call for more information on compatibility between rmware and programming software.
9 Cleaning faceplates
10 Getting Started
