382090 382091 V4.0 09/07
10
4. Connect the voltage test leads and current probe to the electrical equipment under test.
CAUTION: Turn the meter off before connecting the voltage test leads
and the current probe to the electrical equipment under test.
Connect the black voltage alligator clip to the Neutral Line “N”.
Connect the red voltage alligator clip to Line “A”.
Press the I1 current probe trigger to open the jaw and then fully enclose Line “A”.
To measure ground leakage current, press the I4 current probe trigger to open the
jaw and then fully enclose the Ground Line “G”.
5. To measure frequency, press the “Hz” key.
To measure the phase angle, press the “Θ” key.
To measure the ground leakage current, press the “I4” key.
To measure the power factor, press the “PF” key.
6. To measure energy, press the “ENERGY” key, the “Pt”, “Qt”, “St” and “PFt” or “ψt”
annunciators and energy integration start time will display.
The energy integration value and the current time will continually update. Press the “ ↵ ”
key to pause the energy calculation; the HOLD annunciator will display. Press the
HOLD key to exit the energy measurement mode.
