Magnetic Field Detection
1. Hold the meter in the area under test.
2. A magnetic field is present if either the clockwise or the counter-
clockwise LED illuminates.
Battery replacement
The meter uses a 9V battery (supplied) as a power source. If the green
LED does not light when the ON/OFF button is pressed, replace the
battery.
1. Place the meter on a clean, flat, non-abrasive surface.
2. Loosen the rear bottom Phillips head screw to access the
battery compartment.
3. Lift the battery access door and replace the 9V battery observing
polarity.
4. Place the battery carefully in the compartment without crimping
the black and red battery connecting wire.
5. Close the access door and secure the screw.
Calibration and Repair Services
Extech offers repair and calibration services for the products we
sell. Extech also provides NIST certification for most products. Call
the Customer Care Department for information on calibration services
available for this product. Extech recommends that annual
calibrations be performed to verify meter performance and accuracy.
