Extech Instruments EX830 User Manual

EX830A-en-GB_v5.8 5/17
11
Specifications
Function Range & Resolution Accuracy (% of reading + digits)
AC Current
50/60 Hz
400.0 AAC ± (2.5% + 8d)
1000 AAC ± (2.8% + 5d)
DC Current
400.0 ADC ± (2.5% + 5d)
1000 ADC ± (2.8% + 5d)
AC Voltage
50/60Hz
400.0 mVAC ± (1.0% + 10d)
4.000 VAC
± (1.5% + 5d)
40.00 VAC
400.0 VAC
600 VAC ± (2.0% + 5d)
DC Voltage
400.0 mVDC ± (0.8% + 2d)
4.000 VDC
± (1.5% + 2d)
40.00 VDC
400.0 VDC
600 VDC ± (2.0% + 2d)
Resistance
400.0Ω
± (1.0% + 4d)
4.000kΩ
± (1.5% + 2d)
40.000kΩ
400.0kΩ
4.000MΩ
± (2.5% + 3d)
40.00MΩ
± (3.5% + 5d)
Capacitance
4.000nF ± (5.0% + 30d)
40.00nF ± (5.0% + 20d)
400.0nF
± (3.0% + 5d)
4.000µF
40.00µF
400.0µF ± (4.0% + 10d)
4.000mF ± (10% + 10d)
40.00mF unspecified
Frequency
4.000kHz
± (1.5% + 2d)
Sensitivity: 100V (<50Hz); 50V (50 to 400Hz); 5V (401Hz to 4000Hz)
